🔍Track-Mounted Wire Saw Machine – 11KW / 22KW / 37KW
Track-mounted wire saw for precision vertical and overhead cutting. 11KW to 37KW — the standard choice for high-rise wall cutting, elevator shafts and stairwell openings.
The Kowis Track-Mounted Wire Saw is designed for precision vertical and overhead cutting where a crawler cannot reach. Bolted to a track on the wall, the machine climbs and cuts concrete in any orientation — vertical, horizontal or inclined. Available in 11KW, 22KW and 37KW to match the cut depth and speed you need.
Technical Specifications
| Model | KS-WS-T11 / KS-WS-T22 / KS-WS-T37 |
|---|---|
| Motor Power | 11KW / 22KW / 37KW |
| Power Supply | 380V / 50Hz (customizable) |
| Wire Speed | 0–25 m/s (variable) |
| Wire Diameter | 10.5–11.5 mm |
| Mounting | Track-mounted (bolt-on rail system) |
| Cutting Orientation | Vertical / Horizontal / Inclined |
| Weight | Approx. 280 kg (37KW head) |
Key Features
- Track-mounted design for vertical, horizontal and angled cutting
- 11KW / 22KW / 37KW power range
- Precision feed control for smooth, clean cuts
- Lightweight frame for easy rigging and transport
- Compatible with diamond wire up to 11.5mm
Typical Applications
- High-rise wall cutting
- Elevator shaft openings
- Stairwell creation
- Concrete beam and column cutting
- Pipe and duct penetration openings
